Description
UV laser printer specs can be found below. To find out more about this printer and speak to one of our agents please click here
| Model | ECL7203 |
| Laser type | UV Laser |
| Laser power | 3W |
| Cooling system | Water cooling |
| Coding line | Within the marking area |
| Character height | 0.66 – maximum marking range |
| Barcode | Variety of 1D and 2D barcode types available |
| Graphics format | BMP/DXF/HPG/JPEG/PLT and many other graphic formats |
| Text type | Fixed text, serial number, date, counter, shift code, database random code |
| Marking area | 70*70mm – 175*175mm optional |
| Operation interface | 10.1 inches high precision industrial touch screen |
| Operation system | EC-Jet “SEQ” operation system |
| Standard interface | Shaft encoder interface, product detector interface, external alarm interface, USB, Ethernet interface |
| Appearance and material | Industrial – grade stainless street and aluminum cabinet |
| Protection level | IP54 |
| Power supply | 110V – 240VAC, 50/60Hz, 600W |
| Dimensions | Laser head: 580mm * 228mm * 176mm |
| Controller: 564mm * 500mm * 296mm | |
| Handheld touch screen: 272mm * 218mm * 26mm |
